RT～+100℃

 -20℃～+100℃   -40℃～+100℃

GB2423.3-2006 (IEC68-2-3) test Ca: Damp heat constant

The condition of GBT10592-1989 high and low temperature test box

GB2423.1-2008 (IEC68-2-1) test A: low temperature test method

GB2423.2-2008 (IEC68-2-2) test B: high temperature test method

GB2423.4-2006 (IEC68-2-4) test Db: cyclic damp heat test.

SJT31391-1994 test requirements of readiness and methods of inspection and assessment

1. Fast and efficient energy saving of pure imported compressor units

1. Can choose (Bitzer Germany / Italy Fujitsu HO) semi hermetic refrigeration compressor unit, century French "Taikang" full closed refrigeration compressor unit, each unit were after the European Computer Networking itemized monitoring and security code, through the Internet search.

2. For different box temperature requirements, the selection of different units, Ting Yi instrument to ensure the experimental box of cooling rate and can reach the minimum required temperature, the temperature is lower than - 40 box using bipolar cascade refrigeration unit and cascade refrigeration system, including a high pressure refrigeration cycle and a low pressure refrigeration cycle.

The 3 connector for evaporative condenser, evaporator condenser will function as evaporator low-pressure circulation as high condenser cycle with temperature not exceeding -40 temperature as long as the unit can be used.

4 constant temperature and cooling by battery valve to control the cooling output size, than the traditional thermal balance method saves about 30% of energy, greatly reducing the user cost. After baking machine test, multiple data comparison and improvement.

Two. Large screen high performance controller three yuan /TEMI series

Powerful functions, easy to use, interface pretty outrageous

Using the computer technology, the advanced PID control method to measure and control the temperature and humidity of the environment, and can be used with constant temperature and humidity equipment. Alternating high and low temperature test box, suitable for more suitable test box with constant temperature and humidity, dust and rain xenon lamp UV ozone salt fog test box.

Can display and control interface is clear and intuitive touch, select menu, easy to use, stable and reliable performance.

This program control is flexible, cost-effective.

The input channel and output channels can be arbitrarily extended

1 touch screen 3.5 inch /4.3 inch /5.7 inch and 7 inch /9 inch

Two 2 control methods: program / set value, the program can edit 120 sets of programs, the maximum can be compiled for 100 sections, the group of all cycle, the segment cycle;

3 sensor type: two PT100 input (optional electronic sensor input

4 products show clear intuitive three-dimensional sense of strong, programmable control system is flexible and convenient operation, stable performance, more efficient work; flexible installation method, 5 can be embedded or embedded installation

6 alarm signal: 16 DI external obstacle alarm;

7 temperature measurement range: --200.00 C -90.00 C, (optional --300.00 C -90.00 C) error + 0.2 c;

8 humidity measurement range: 1.0%--100%RH, the error is + 1%RH;

9 communication interface: (RS232/RS485, communication the longest distance 1.2km[optical fiber up to 30km]);

10 interface language type: Chinese / english;

11 Chinese character input function, edit input manufacturers information, fault name, test name, etc., display intuitive, clear;

12 curves: real time temperature, humidity PV, SP curve;

13 with network function IP address can be set; can bring the printer (USB function optional); remote control instrument;

Three. New, CommScope granular activated carbon filter, water filter and even drinkable

Perfect solution part of the use of pure distilled water, and lead to poor water quality due to the problem of poor water

Four. / Schneider / CHINT and other well-known Delixi electrical components

Performance is stable and unparalleled, long and durable to prevent the problem of circuit

ive. Excellent effect and refrigeration accessories

The Danfoss, evaporating pressure regulating valve to make the evaporation pressure of the system is kept constant, the surface of the evaporator temperature could be controlled by regulators in the suction pipe on the throttle, so as to avoid long time of low temperature and high humidity or temperature and humidity test evaporator icing test abnormal phenomenon caused by the. The Japanese Heron works two solenoid valves, valve coil battery shell protection class up to IP67.

The Emerson Shuangliu thermal expansion valve closure, the expansion valve through the end of the evaporator superheat change to adjust the flow, prevent the emergence of evaporator using area and the compressor cylinder knocking phenomenon.

ALCO two pass filter.

Six. Safety and rest assured that a variety of protection systems do not have to worry about hidden dangers

With over temperature alarm, leakage protection, under phase lack phase protection, over current protection, fast fuse device, a compressor high and low voltage protection, compressor overheat protection, compressor over current protection, line fuse and the sheath type terminal and grounding protection.

○ The use of ambient temperature 5 to 35 DEG C, the best use temperature: 15 to 25 DEG C, relative humidity: atmospheric pressure: 86-106Kpa = 85%RH

○ Ground level, well ventilated, non flammable, explosive, corrosive gas and dust.

○ There is no strong airflow around, when the ambient air is forced to flow, the air flow should not be blown directly into the box.

○ No electromagnetic field near, without direct sunlight, other thermal radiation source

○Proper maintenance space is left around the equipment.

○ Ground bearing requirements of more than 600kg/ square meters (the upstairs venue)

○ Venue: drainage test box near the best can have faucet and floor drain
